Michelangelo prosthetic hand
How the Michelangelo works
The Michelangelo prosthetic hand features a highly natural design that’s built on incredible technology.
It will give you more ways to move your hand, and make all sorts of everyday tasks easier and more natural. Imagine being able to grasp and hold objects with greater control—and less effort.
Grip the way you need to
The Michelangelo® Hand features complex gripping kinematics—offering more patterns than any other prosthetic hand—and combines incredibly natural appearance with low weight.
The main drive is responsible for the gripping movements and grip force. The thumb, index finger and middle finger are actively driven while the ring finger and little finger passively follow the other fingers.
Self-suspending socket with flexible inner socket and laminated frame provides an intimate fit while maintaining a strong connection to the electrodes used to control the hand.
Wrist joint looks—and acts—naturally
The oval hand adapter has a very natural appearance. Flexion and extension are based on the position of a relaxed wrist (‘Flexible’ Mode). Passive inward and outward rotation is also supported. The wrist can be rotated (and locked, at 15 degree increments). It can also be locked in ‘Rigid’ mode at several flexion and extension angles.
Charging the battery is a snap.
The Michelangelo’s charger attaches to the system with the help of an integrated magnet, which helps the components align quickly and easily.
Separately movable thumb
The thumb drive allows for a variety of positions. Rotating the thumb outward creates a flat, open hand for additional movements.
Based on nature down to the details; the fingers are made of a combination of soft and hard materials.
Hand in glove
The AxonSkin prosthetic glove comes in 6 colors. Made out of multiple layers of PVC, the gloves keep out dust and dirt and match natural skin structure down to knuckles and veins.
A translucent glove is also available to highlight Michelangelo’s unique design.
Our Patient Navigator can provide information and connect you with more resources.
Get in touch
What you need to know
Advantages for you
The Michelangelo prosthetic hand: Intelligently simple
The Michelanglelo’s thumb, index and middle fingers are actively driven, while the ring and pinky passively follow the other fingers—and can support objects from below, such as a can.
The fingertips are made of a combination of soft and hard materials to allow real precision when grasping objects.
Michelangelo is the first thumb in the world that can be positioned electronically. While most hands have only a single drive unit to control the gripping action, the Michelangelo has a second thumb drive unit to allow you to position the thumb with myoelectric controls.
The multiaxial movement pattern minimizes unnatural compensating movements and promotes a healthy, natural body posture.
The hand returns to a natural rest position when not being actively used.
Quick change artist
Michelangelo has three position modes, offering 7 grip types—including open palm and a powerful key grip.
Open new doors
The oval AxonWrist flexes, extends, and rotates for the most natural acting wrist function available.
Hand in glove
NEW! Now introducing the latest glove option for the Michelangelo Hand, Axon Silicone glove. The Axon Silicone glove offers a more natural look and feel and is available in colors 2, 4, 6, 8 and 10.
Love our Axon SkinNatural PVC glove? Not to worry, it’s is also available, in addition to our visual (translucent) and black gloves.
Now with Active Rotation!
NEW! AxonRotation featuring active AND passive rotation. By combining the hand’s seven different grip patterns and automatic thumb positioning with active rotation, there is now greater functionality for the user. Ideal for both unilateral and especially bilateral users. The AxonRotation is programmed for more intuitive and effective use benefitting the user in many ADLs.
Precision and Versatility: Introducing the AxonHook
For maximum versatility, precision and power, look for the LATEST addition to the AxonBus Family: the AxonHook. The AxonHook is the perfect complement to the Michelangelo Hand. Offering titanium with Polyurethane coated fingers, the AxonHook is precise and powerful, the perfect companion to the Michelangelo Hand – ready for any technical task.
Michelangelo lets you grab hold with 7 hand positions!
The Michelangelo has three position modes, offering 7 grip types—including open palm—as well as a neutral position and the most natural wrist action available.
Thumb moves sideways to index finger
Thumb moves towards a tripod pinch with the index and middle fingers
Finger Abduction/adduction mode:
The only prosthetic hand in the world to have powered abduction/adduction. Regardless of thumb position, the fingers themselves help you to hold several flat, thin objects, such as credit cards, between the fingers.
Thumb and fingers return to a relaxed, natural position when not actively being used
The mechanical AxonWrist can be flexed, extended and rotated, but it really stands out in its flexible mode, where it takes on the appearance of a relaxed wrist joint. It helps to prevent unnatural compensating movements while keeping your posture healthy. The wrist can also be rotated and locked at 24 points in 15 degree increments—and can also be locked at various angles of flexion and extension.
The right therapy is essential
The right therapy is critical for success with the Michelangelo Hand and it’s important that you work closely with your therapy team, which may include your prosthetist, a physical or occupational therapist, your doctor—and even your family and friends.
For the best outcome, prosthesis training is divided into three phases that build on each other:
Controls training Therapy aimed and helping you learn how to control the prosthesis.
Repetitive drills Exercises to be repeated until using the hand become second nature.
ADL training How to use the prosthesis to its best advantage for everyday activities.
To find out more about therapy, please visit our Info for upper limb amputees pages.
Take a look at our Frequently Asked Questions for more information.
Talk to your prosthetist about the Michelangelo below elbow prosthesis and if it’s the right solution for you. He or she will also be able to advise you on the fitting of this advanced technology—and explain how it might be paid for by insurers.
Don’t have a prosthetist? Find a qualified prosthetist near you.
Except for certain products available at www.mobilitydirect.com, patients cannot purchase products directly from Ottobock. Ottobock products are generally prescribed by physicians or clinicians, who provide the product to the patient.
If you’d like to be fit with an Ottobock product, please talk to your physician or clinician (orthotist, prosthetist, therapist, or Rehab Technology Specialist).
If you have further questions, please call 800 328 4058 and ask for our Consumer Support Specialist.
Ottobock has recently developed an above-elbow prosthesis system that works with the Michelangelo Hand. Ask your prosthetist if this solution is right for you.
Your ability to ride your bicycle depends on the amputation level and the type of prosthesis you have. The Axon-Bus prosthetic system was developed for everyday use and must not be used for unusual activities, for example, sports with excessive strain and/or shocks to the wrist unit (pushups, downhill, mountain biking) or extreme sports (free climbing, paragliding, etc.). Always refer to the the Instructions for Use manual before wearing your Michelangelo hand.
Depending on your occupation, you can go back to work with your prosthesis. If your work involves extreme physical strain, you should let your prosthetist know before the pros¬thesis is fabricated, because the type of stress applied to the prosthesis affects the manufacturing of the socket, as well as the selection of components. Various terminal devices, such as the Ottobock System Greifer may be helpful for specific tasks.
Your everyday prosthesis is not suitable for swimming or taking a shower. Talk to your prosthetist about a specialized swimming prosthesis.
Not finding what you are looking for? Please contact us!
